FEEL THE FLOW
AND BUILD YOUR OWN
MASTERLIQUID MAKER 240

INTRODUCING
THE MASTERLIQUID MAKER 240
Cooler Master is a world leading thermal solution provider with a long history of high performance, innovative thermal solutions for the PC. It now introduces its first liquid cooling kit for CPUs, blending high performance, low noise with an extensible design that allows users the flexibility to customize it to meet their needs. It includes a pure copper CPU block with two 120mm MasterFan Pro RGB fans that features an innovative negative noise technology and an ultra-low noise pump enabling the best possible cooling in silence. It gives the user build flexibility and the ability for future upgradability, while looking awesome with its RGB lighting effects.

f01 top cover f01 bottom cover
HIGH PERFORMANCE PUMP
Our high performance tri-phase PWM water pump/reservoir combo comes with our exclusive in-house design impeller for a more powerful pump.
3 FILL PORTS
Extendable, flexible and build your custom loop
CLEAR RESERVOIR
The unique transparent circular acrylic liquid reservoir allows you to show off your coolant color in style
HIGH PERFORMANCE
IMPELLER
Cooler Master exclusive in-house design impeller enhances the liquid pressure to the water block
CARBON BEARING
With great corrosion resistance, it could withstand all variety of coolants and perating conditions while performing at its best
TRI-PHASE/PWM MOTOR
WITH SILENT DRIVER
Minimizing operating current while keeping a low dBA. The first ever cooler to proivide wide range PWM function to adjust the pump speed without opening the chassis

f01 top cover f01 bottom cover
WATER BLOCK
CONTINUOUS JET IMPINGEMENT COOLING
Generates powerful liquid pressure
and directing the liquid to elminate hot spots in the cooler
PURE COPPER
COMPRESSION FITTING
Provides a quick, easy and secure install
O-RING MADE OF HIGH
QUALITY EPDM RUBBER
Eliminates and prevent liquid emission
WATER BLOCK CAP
Pure copper material and the standard G1/4 threading is compatible with most of the DIY liquid cooler components in the market
CONTINUOUS JET
IMPINGEMENT COOLING
Generates powerful liquid pressure and directing the liquid to elminate hot spots in the cooler
MICROCHANNEL
COLD PLATE
Precision machined copper microchannels maximize the water contact surface to swiftly dissipate heat.

f01 top cover f01 bottom cover
HIGH PERFORMANCE
COPPER CORE RADIATOR
Copper core radiator with a compact size
that can fit most cases while also providing best-in-class performance.

PREMIUM COOLANT
IMPROVES LONG-TERM
RUNNING RELIABILITY
The premium coolant is created with a effective anti-corrosion solution to protect the cooling system and improve the heat transfer to provide the best cooling performance.

DO YOU WANT TO SEE THIS COOL DEMO EFFECT?
This site is recommended to Internet Explorer 9 above
Firefox or Google browser browser

STATIC
MODE
TRY TO CLICK ON DIFFERENT MODE
▼ ▼ ▼
RGB IN THE PALM OF YOUR HAND
WITH INCLUDED WIRED RGB CONTROLLER
A compact size RGB LED controller that allows you to easily customize your RGB devices without the need for either an RGB capable motherboard or software. You can have the colorful rig you’ve always wanted with just the touch of a button.
MODE SWITCH
6 PRE-SET EFFECTS TO SELECT
COLOR SWITCH
ADJUST THE COLOR BASED ON
THE EFFECT SELECTED
BRIGHTNESS
ADJUST THE BRIGHTNESS

Specifications
Product Name MasterLiquid Maker 240
Model MLZ-N24L-C20PC-R1
CPU Socket Compatibility Intel® LGA 2066 / 2011-v3 / 2011 / 1151 / 1150 / 1155 / 1156 socket

AMD® AM4 / AM3+ / AM3 / AM2+ / AM2 / FM2+ / FM2 / FM1 socket
PURE COPPER CPU BLOCK
Dimensions Ø84 x 18.9 mm (3.3 x 0.7")
LOW NOISE PUMP-RESERVOIR COMBO
Combo Dimensions 76 x 76 x 200 mm (3 x 3 x 7.9")
Pump Connector 4-Pin (PWM)
Rated Voltage 12 V
Rated Current 0.65 A
HIGH PERFORMANCE RADIATOR
Dimensions 280 x 124 x 29.2 mm (11 x 4.9 x 1.15")
Material Copper core (with Aluminum Frame)
MASTERFAN PRO 120 RGB
Quantity 2 pcs
Dimensions 120 x 120 x 25mm (4.7 x 4.7 x 1")
Fan Speed 650 ~ 2000 RPM ± 10%
Fan Airflow 66.7 CFM
Fan Air Pressure 2.34 mmH2O
Noise Level 6 ~ 30 dBA
MTTF 490,000 hours
L-10 Life 70,000 hours
Rated Current 0.18 A
Connector 4-Pin
COMPRESSION FITTING
Quantity 6 pcs
Thread G 1/4
ID 3/8"
OD 5/8"
FILL PORT CAP
Quantity 3 pcs
Thread G 1/4
TUBING
Length 1.2 Meter
ID 3/8"
OD 5/8"
PREMINUM COOLANT
Capacity 100 mL
Color Pink
ACCESSORY
1-to-2 Fan Splitter x 1
1-to-3 RGB Splitter x 1
Wired RGB Controller x 1
Pump-Reservoir Mounting Bracket x 1
EAN Code 4719512061022
UPC Code 884102033629
?
